The implanting of metal products is performed with numerous surface treatments because of toxicity and adhesion. Recently, the surface modification of metal products has been actively studied by coating the surface of the TiC or TiN film. We prepared a Ti(10%)Ag Target which may be used in dental oral material by, using the AIP(arc ion plating) system TiAgN coating layer that was deposited on Ti g.23. The purpose of this study was to establish the optimal bias voltage conditions of the coated TiAgN layer formed by the AIP process. The TiAgN coatings were prepared with different bias voltage parameters (0V to −500V) to investigate the effect of bias voltage on their mechanical and chemical properties. The SEM(scanning electron microscope), EDS(energy dispersive X-ray spectrometer), XRD(X-ray diffraction), micro-hardness, and potentiodynamic polarization were measured and the surface characteristics of the TiAgN coating layers were evaluated. The TiAgN coating layer had different mechanical characteristics based on the bias voltage, which also showed differences in thickness and composition.

Abstract
 1. 서 론
 2. 실험 방법
  2.1 시편준비
  2.2 AIP를 이용한 TiAgN Coating
  2.3 TiAgN코팅층 분석
 3. 결과 및 고찰
  3.1 TiAgN 코팅층 두께관찰(10,000배율)
 4. 결 론
 Acknowledgement
 References

• 백민숙(순천대학교 미래전략신소재공학과) | Min-Sook Baek Corresponding author
• 윤동주(차세대 전략산업용 희유자원 실용화센터) | Dong-Joo Yoon
• 강병모((주)오티앤티) | Byeong-Mo Kang
• 정운조((주)오티앤티) | Woon-Jo Jeong
• 김병일(순천대학교 미래전략신소재공학과) | Byung-Il Kim
