SUS hexagonal bar, which is manufactured by drawing process of SUS circular bar, have been widely used to make various adapters and fittings. The purpose of this study is to investigate the characteristics and stability of variable roll unit including stand module. Stand module is essential part of variable roll unit. Structural analysis was performed to predict the stability of stand module using 3 loads (50, 75, 100 Ton), thus it may be of help to the manufacture of stand module. As the results, internal ring of bearing showed maximum equivalent stress, and moreover bearing, shaft and roller had to be preferentially considered in order to maintain its stability. In cases of 50 and 75 Ton, there were no problems for stabilities, respectively, on the other hand, problem for stability may occur in case of 100 Ton.

ABSTRACT
 1. 서론
 2. 인발 공정(Drawing process)
 3. 모델링 및 수치해석 방법
 4. 해석 결과 및 고찰
 5. 결론
 후기
 References

• 이영식(Han Young Machinery Co., Ltd.) | Young-Sik Lee
• 양영준(Gyeongnam Nat'l, Univ. of Sci. & Tech., Automotive Eng.) | Young-Joon Yang Corresponding Author
