A thermal-optical transmittance carbon analyzer has been developed to determine particulate organic (OC) and elemental (EC) carbon. Several analysis factors affecting the sensitivity of OC and EC determination were investigated for the carbon analyzer. Although total carbon (TC) is usually consistent in the determination, OC and EC split is sensitive to adopted analysis protocol. In this study the maximum temperature in oxygen-free He in the analysis was examined as a main cause of the uncertainty. Prior to the sensitivity analysis consistency in OC-EC determination of the carbon analyzer and the uniformity of carbonaceous aerosol loading on a sampled filter were checked to be in acceptable range. EC/TC ratios were slightly decreased with increasing the maximum temperature between 550-800oC. For the increase of maximum temperature from 500oC to 800oC, the EC/TC ratio was lowered by 4.65-5.61% for TC loading of 13-44 μg/cm2 with more decrease at higher loading. OC and EC determination was not influenced by trace amount of oxygen in pure He (>99.999%), which is typically used in OC and EC analysis. The facing of sample loaded surface to incident laser beam showed negligible influence in the OC-EC split, but it caused elevated PC fraction in OC for forward facing relative to backward facing.

Abstract
 1. Introduction
 2. Materials and Methods
  2.1. Instrumentation of Carbon Analyzer
  2.2. OC-EC Analysis Protocol
 3. Results and Discussion
  3.1. Uniformity of Carbonaceous Aerosol Loading
  3.2. Effects of the maximum temperature in He onOC-EC determination
  3.3. Sensitivity of OC-EC determination to traceoxygen in He and filter facing
 4. Conclusion
 References

• Ho-Jin Lim(Department of Environmental Engineering, Kyungpook National University) Corresponding author
• Su-Hwan Sung(Department of Chemical Engineering, Kyungpook National University)
• Sungsin Yi(Department of Environmental Engineering, Kyungpook National University)
• Jun-Hyun Park(Department of Environmental Engineering, Kyungpook National University)
