하중 보상을 이용한 회전 구동부의 처짐 특성 연구

김현식

논문 상세보기

하중 보상을 이용한 회전 구동부의 처짐 특성 연구 KCI 등재

Study on the Deflection Characteristics of Rotating Drive by Weight Compensation

김현식

언어KOR
URLhttps://db.koreascholar.com/Article/Detail/366089

구독 기관 인증 시 무료 이용이 가능합니다. 4,000원

한국기계기술학회지 (Journal of the Korean Society of Mechanical Technology)

제20권 제6호 (2018.12)
pp.790-795

한국기계기술학회 (Korean Society of Mechanical Technology)

초록

In this study, we analyzed the structural safety and vibration characteristics of rotational drive in 3D CT scan equipment using finite element analysis. The analysis results showed a safety factor of 9.2 and a left and right vertical deflectional deviation of 0.24mm from the maximum equivalent stress. After applying weight compensation of 27.7kgf, the structural analysis reduced the safety factor to 7.6, but the deflectional deviation of the left and right structure was reduced to 0mm. Also, we presented the optimum design of rotational drive through the vibration analysis.

키워드

Rotational drive 회전 구동부 Equivalent stress 등가응력 Deflectional displacement 처짐량 Natural frequency 고유진동수

ABSTRACT
1. 서 론
2. 본 론
  2.1 해석 모델
  2.2 해석 전처리
  2.3 구조해석 결과
3. 고 찰
4. 결 론
References

저자

김현식(Division of Automobile Engineering, Vision College of Jeonju) | Hyun-Sik Kim Corresponding Author
