양형 IMS 모듈 튜블러 샤프트의 스플라인 가공 개선 KCI 등재

Improvement of Tubular Shaft Yoke Spline Machining in Both Side IMS Module

  • 언어KOR
  • URLhttps://db.koreascholar.com/Article/Detail/366157
구독 기관 인증 시 무료 이용이 가능합니다. 4,000원
한국기계기술학회지 (Journal of the Korean Society of Mechanical Technology)
한국기계기술학회 (Korean Society of Mechanical Technology)
초록

The objective of this study is to solve a problem that is occurred during the spline machining of tubular shaft yoke in both side IMS module. In order to simulate the problem, the movement direction of upper die was set as standard case and error case. The material of tubular shaft yoke was set to S20C as refer to the analysis library. The movement directions of upper die were separated with standard case and error case. The error case was set to simulate the problem in the spline machining of tubular shaft yoke. In order to solve the problem, the outer radius of upper die were modelled from 9.40mm to 9.44mm. The simulation results were analyzed and compared in terms of effective stress, metal flow line and folding phenomena characteristics. In case of the outer radius of upper die was 9.42mm, it was observed a relatively uniform effective stress distribution and had a straight metal flow line.

목차
ABSTRACT
 1. 서 론
 2. 수치 해석적 연구 방법
  2.1 스플라인 가공을 위한 금형
  2.2 수치해석 조건
 3. 결과 및 고찰
  3.1 유효 응력(Effective stress) 특성
  3.2 금속 유동선(Metal flow line) 특성
  3.3 접힘 현상(Folding phenomena) 특성
 4. 결 론
 References
저자
  • 민세훈(Kongju National University) | Se Hun Min
  • 서현규(Division of Mechanical & Automotive Engineering, Kongju National University) | Hyun Kyu Suh Corresponding Author
