ㅊBy controlling the piston speed of the gas spring applying to the digital television stand application of the gas spring, a user can operate the elevation when the gas spring is working under long stroke(200～300 mm, the TV elevation displacement). According to stroke, by some devices with the problem rising from between the difference of external forces, the emotional quality in television elevational function is realized. The piston speed control technique is investigated to perform this experiment piston flow analysis and flow rate control for precise tubular cross section and propose a piston structure for elevation action. This study is for the development of the gas spring of the large size television stand with 50 inch over. In the gas spring development of elevation working, a device to compensate for the volume of the cylinder is generated as much the volume of the piston rod. As this study result, at the development of working gas spring, the hollow shaft is more favorable than the solid one in the apparatus to compensate for the cylinder volume generated.

Abstract
 1. 서론
 2. 높이 조절 동작용 가스스프링 개발의 목표 및 내용
  2.1 기술개발목표
  2.2 기술개발내용
 3. 결론
 References

• 이정익(Dept. of Mechanical Design, INHA Technical College) | Jeong-Ick Lee
• 고병갑(Dept. of Mechanical Engineering, INHA Technical College) Corresponding Author
