In this study, in order to solve the quality problem (Safety accident) that the chain breaks out of the wheel gear due to the problem of the spare tire carrier device, the wheel gear is rotated in such a way that the upper part of the chain is caught on one side of the triangular wheel gear. When falling, the tire falls due to the chain falling off and the chain is caught by the wheel gear so that it cannot bear the tire load and slip occurs. Also, in order to solve the quality problem that the chain is caught (Due to malfunction), the “ㄷ” shaped chain the guide should play the role of guiding the movement of the chain by holding the chain in the direction. The technical development goal is to solve the problem of the chain dropping and the chain hanging from the wheel gear of this product.

ABSTRACT
1. 서 론
2. 기술 개발 목표 및 내용
    2.1 기술 개발 목표
    2.2 기술 개발 내용
3. 성능 시험 및 시험 결과
    3.1 스페어타이어 캐리어 작동 내구
    3.2 체인 파단 하중시험
    3.3 스페어타이어 캐리어 진동내구시험
    3.4 휠 기어 경도 시험
4. 결 론
References

• 임경채(Dept. of Machanical Engineering, Kunsan National University) | Kyeong-Chae Lim Corresponding Author
