pp.1-8
PURPOSES: Investigating road pavement conditions using an investigation vehicle is challenging especially if repeated driving is required on the by-lane, and the traffic in the investigation section is heavy. A technology used to investigate the road pavement conditions is studied herein using image data obtained by drone photography.
METHODS : Flight plans were made for the survey areas, and ground control point measurements were performed. The research section was filmed using drones. The acquired image data were modeled using Pix4Dmapper. The images taken by the drones were used to investigate the road pavement cracks. A digital surface model was extracted from the Pix4Dmapper modeling results using the Global Mapper program to investigate plastic deformation and flatness. As regards plastic deformation, the elevation of each point was extracted at intervals of 50 cm and 10 cm in the longitudinal and lateral directions, respectively, for 20 m× 10 m of the entire road. In terms of flatness, the elevation values for each point were extracted at intervals of 5 cm and 10 cm for the wheel path and 20 m for the entire roadway.
RESULTS: This study compared drone-captured images, which were consistent, and vehicle scan images and confirmed that the former can detect a large number of cracks on road surfaces. The results showing the difference in the elevation values of the road surface indicate that the section, wherein the plastic deformation occurs throughout the entire road surface, can be identified and evaluated. With regard to flatness, in future studies, the long-directional elevation value of the target segment extracted using Global Mapper is likely to be derived from the International roughness index, which is the international flatness index used in the ProVAL program developed and used by the Federal Highway Administration.
CONCLUSIONS : The road pavement status investigation conducted herein by utilizing drone-acquired images showed that repeated driving in a section is not required, and various analyses can be made in a single shot. If technologies, such as artificial intelligence, big data, and Internet of Things, which are the key components of the Fourth Industrial Revolution, are adapted, they can be used to investigate road pavement conditions and inspect completely constructed road lines and major road facilities.
1. 서론
2. 드론 선행 연구 사례
2.1. 국내 사례
2.2. 국외 사례
3. 드론 촬영 개요
4. GCP 설치 및 드론 운용
4.1. 비행 계획
4.2. GCP(Ground Control Point)측량
4.3. 드론 운용을 통한 데이터 취득
5. 사진정합 및 데이터 추출
5.1. Pix4D Mapper를 활용한 사진정합
5.2. Global Mapper를 활용한 데이터추출
6. 데이터 분석
6.1. 균열
6.2. 소성변형
6.3. 평탄성
7. 결론
