Various electronic control parts and devices installed in electric vehicles have greatly improved the convenience of occupants, but electromagnetic waves emitted from electronic devices have greatly increased concerns about malfunctions, deterioration of performance, safety accidents, etc. There are two models of analysis. Case A is symmetrical about one axis of rotation. Case B has two axes of rotation. In this study, a flow analysis was conducted to find excellent flow conditions in the mixing process to develop a paint with excellent electromagnetic shielding and thermal insulation performance. The results of the flow analysis are reflected in manufacturing specifications and are intended to be used to develop high-quality systems.

ABSTRACT
1. 서 론
2. 도료 혼합기의 설계
    2.1 고성능 도료제조용 시스템
    2.2 혼합시스템의 공정
3. 혼합장치의 유동해석
    3.1 수치해석
    3.2 해석조건
    3.3 수치해석의 지배방정식
    3.4 유동해석의 결과
4. 결 론
References

• 김진택(Division of Mechanical System Engineering, Jeonbuk National University) | Jin-Taek Kim
• 송준희(Division of Convergence Technology Engineering, Jeonbuk National University Department of Energy Storage/Conversion Engineering of Graduate School, Jeonbuk National University) | Jun-Hee Song Corresponding Author
