A Study on the Spectral Transmittance of UV-Blocking Contact Lenses KCI 등재

자외선 차단 콘택트렌즈의 광투과율에 관한 연구

  • 언어KOR
  • URLhttps://db.koreascholar.com/Article/Detail/399914
구독 기관 인증 시 무료 이용이 가능합니다. 4,000원
대한시과학회지 (The Korean Journal of Vision Science)
대한시과학회 (The Korean Society Of Vision Science)
초록

목적 : 국내에서 유통되고 있는 하이드로겔 콘택트렌즈의 광투과율을 측정하여 가시광선 및 자외선 차단 기준 규격에 부합하는지 알아보고자 하였다.
방법 : 자외선 차단 표시가 있는 콘택트렌즈를 포함한 하이드로겔 콘택트렌즈 14종을 임의로 선정하였다. 실험 렌즈의 광투과율 측정범위는 가시광선, UV-A 및 UV-B로 하였다. 가시광선은 ANSI Z80.20:2004를 참고하였고, 자외선은 ISO 와 FDA 기준을 참고하여 비교하였다. 자외선 차단 표시가 있는 렌즈의 경우 기준에 따라 Class 1, Class 2로 분류하였다.
결과 : 실험렌즈 14종의 가시광선 광투과율 측정결과 투명 콘택트렌즈 7종 중 4종의 렌즈는 88% 이하로 나타났 으나, 범위에 크게 벗어나지 않았다. 그리고 컬러 콘택트렌즈는 7종 모두 70% 이상으로 나타나 기준규격에 부합하 였다. 자외선 투과율 측정결과 자외선 차단 표시가 있는 콘택트렌즈 10종 중 3종(UD-4, 5, 6)은 UV-A에서 86.67~ 88.59%, UV-B에서 82.41~83.72%로 나타났다. 이 렌즈들의 자외선 광투과율 값은 ISO 및 FDA 기준규격에 부 합하지 않는 것으로 나타났다.
결론 : 국내 유통되고 있는 자외선 차단 콘택트렌즈 중 ISO 및 FDA 기준규격에 부합하지 않은 제품이 존재하 는 것으로 나타났으며, 모두 국내제품인 것으로 나타났다.

Purpose : The purpose of this study was to measure the spectral transmittance of domestic hydrogel contact lenses, and to find out if they meet the standards of visible light and UV-blocking spectral transmittance.
Methods : Hydrogel contact lenses including UV-blocking contact lenses were randomly selected in this study. The range of spectral transmittance measurement in the experimental lenses was set to visible light, UV-A and UV-B. Visible light transmittance was based on ANSI Z80.20:2004. And the UV spectral transmittance was compared to the UV-blocking contact lenses standards applied by the International Organization for Standardization (ISO) and the Food and Drug Administration (FDA). UV-blocking contact lenses were classified as Class 1 and Class 2 according to the standards.
Results : As a result of measuring visible light transmittance of 14 types of experimental lenses, 4 transparent contact lenses showed 88% or less, but did not deviate significantly from the range. And all 7 types of color contact lenses were measured to be over 70% and met the standards. In the spectral transmittance of UV, the UD-4, 5, 6 lenses among the 10 types of UV-blocking contact lenses showed the range of a spectral transmittance of 86.67~88.59% and 82.41~83.47% for UV-A and UV-B, respectively. These UV wavelength values were found to be non-compliant with ISO and FDA UV-blocking standards.
Conclusion : It shows that some UV-blocking contact lenses do not meet ISO and FDA UVblocking standards, and they were all domestic products.

목차
Abstract
Ⅰ. 서 론
Ⅱ. 대상 및 방법
    1. 연구 대상
    2. 연구 방법
Ⅲ. 결 과
    1. 실험렌즈의 파장 별 광투과율
    2. 가시광선 광투과율
    3. 자외선 광투과율
    4. 자외선 차단 콘택트렌즈의 ISO 및 FDA 기준 비교
Ⅳ. 고찰 및 결론
References
요 약
저자
  • Da-Yeon Lee(Dept. of Visual Optics, Graduate School, Health and Welfare, Baekseok University) | 이다연
  • Tae-Hun Kim(Dept. of Visual Optics, Graduate School, Health and Welfare, Baekseok University/Dept. of Visual Optics, Division of Health Science, Baekseok University) | 김태훈
