pp.71-77
PURPOSES : The actual service life of repair methods applied to cement concrete pavement is analyzed based on de-icing agent usage.
METHODS : Highway PMS data pertaining to de-icing agent usage are classified into three grades: low (1~5 ton/lane/year), medium (5~8 ton/lane/year), and high (greater than 8 ton/lane/year). The repair methods considered include diamond grinding, patching, joint repair, partial depth repair, and asphalt overlay on five major highways. The service life of each repair method is analyzed based on the usage level of the de-icing agent.
RESULTS : The service lives of the applied repair methods are much shorter than expected. It is confirmed that the service life afforded by diamond grinding, patching, and joint repair methods are not significantly affected by the use of de-icing agents, whereas that afforded by asphalt overlay and partial depth repair methods is affected significantly. The service life afforded by the asphalt overlay and partial depth repair methods decreases at high usage levels of the de-icing agent (greater than 8 ton/lane/year).
CONCLUSIONS : Among the repair methods considered, the service life afforded by partial depth repair and asphalt overlay is affected significantly by the amount of de-icing agent used. Additionally, the differences between the expected and actual analyzed service lives should be considered in the next-generation maintenance strategy for cement concrete pavements.
1. 서론
1.1. 콘크리트 포장 현황
1.2. 제설제 사용량과 콘크리트 포장 파손
2. 보수공법 수명과 제설제 사용량 상관관계 분석방안
2.1. 고속도로 PMS자료 검토
2.2. 제설제 사용량 자료
2.3. 제설제 사용량이 보수공법 수명에 미치는 영향분석방법
3. 결과 및 분석
3.1. 보수공법별 제설제 영향 수명분포도
3.2. 보수공법별 평균수명과 제설제 영향 분석
4. 결론
REFERENCES
