The seismic behaviors of the arch structure vary according to the rise-span ratio of the arch structure. In this study, the rise-span ratio (H/L) of the example arch structure was set to 1/4, 1/6, and 1/8. And the installation angle of the seismic isolator was set to 15°, 30°, 45°, 60° and 90°. The installation angles of the seismic isolator were set by analyzing the horizontal and vertical reaction forces according to the rise-span ratio of the arch structure. Due to the geometrical and dynamic characteristics of the arch structure, the lower the rise-span ratio, the greater the horizontal reaction force of the static load, but the smaller the horizontal reaction force of the dynamic load. And if the seismic isolator is installed in the direction of the resultant force of the reaction forces caused by the seismic load, the horizontal seismic response becomes small. Also, as the installation angle of the seismic isolator increases, the hysteresis behavior of the seismic isolator shows a plastic behavior, and residual deformation appears even after the seismic load is removed. In the design of seismic isolators for seismic response control of large space structures such as arch structures, horizontal and vertical reaction forces should be considered.

Abstract
1. 서론
2. 아치구조물의 지진응답 특성
    2.1 예제 아치구조물의 동적특성
    2.2 경간-높이비에 따른 예제 아치구조물의지점반력 분석
3. 면진장치 설치각도에 따른 예제 아치구조물의 지진응답
    3.1 예제 아치구조물의 면진장치 적용
    3.2 높이-경간비 1/4 아치구조물 지진응답
    3.3 높이-경간비 1/6 아치구조물 지진응답
    3.4 높이-경간비 1/8 아치구조물 지진응답
    3.5 예제 아치구조물의 면진장치 거동 분석
4. 결론
References

• 김기철(서일대학교 건축과 교수) | Kim Gee-Cheol (Department of Architecture, Seoil University)
• 이준호(서일대학교 건축과 교수) | Lee Joon-Ho (Department of Architecture, Seoil University) Corresponding author
