PURPOSES : This study compared the performance evaluation of a hot mix asphalt (HMA) and asphalt mixture of a warm-antistrip agent. METHODS : A mix design applying Korean standards was conducted to evaluate the performance evaluation. Thereafter, the quality standard evaluation of the asphalt mixture produced was conducted, and if all quality standards were satisfied, a performance evaluation was conducted. Types of performance evaluation included the Hamburg wheel tracking test and dynamic modulus test.
RESULTS : As a result of the Hamburg wheel tracking test, the asphalt mixture with a warm-antistrip agent obtained a lower sedimentation value at 10000 times and 20000 times. This result is considered to have higher plastic deformation resistance of the asphalt mixture with a Warm-antistrip agent than HMA. The U.S. Department of Transportation stipulates that plastic deformation resistance is excellent if the asphalt mixture does not exceed 20,000 times the precipitate of 20 mm. Therefore, we confirmed that the plastic deformation resistance of the asphalt mixture with a warm-antistrip agent was excellent. Additionally, the master curve was analyzed by synthesizing the results of the dynamic modulus test. When analyzing the low load cycle at the bottom left of the master curve, the dynamic modulus value of the master curve was higher in the asphalt mixture with a warm-antistrip agent than in the HMA. In addition, when analyzing the high load cycle part, the dynamic modulus of the HMA was measured to be higher than that of the asphalt mixture with a warm-antistrip agent. Accordingly, the resistance to fatigue cracking of the asphalt mixture with a warm-antistrip agent was considered superior to that of the HMA.
CONCLUSIONS : As a result, we confirmed that the asphalt mixture with a warm-antistrip agent that satisfies the Korean quality standards had better plastic deformation and fatigue resistance for all performance evaluation tests conducted in this study than the HMA. However, since the Hamburg wheel tracking test did not significantly differ in the amount of sedimentation in the performance evaluation tests and the mixture using one additive was compared with HMA, studies on the effects of various additives containing warm-antistrip agents are required.
1. 서론
2. 배합설계
2.1. 일반 가열 아스팔트 혼합물 배합설계
2.2. 중온박리 방지제 혼합물 배합설계
3. 품질시험
3.1. 마샬 안정도 및 흐름값
3.2. 터프니스
3.3. 간접인장강도
3.4. 인장강도비
4. 동탄성계수 시험
4.1. 동탄성계수 시험방법
4.2. 동탄성계수 시험결과
4.3. 종합 마스터커브
5. 함부르크 휠 트래킹
5.1. 함부르크 휠 트래킹 시험방법
5.2. 합부르크 휠 트래킹 시험 결과
6. 결론
REFERENCES
