각도 분할 인덱스 척의 구조 안정성에 대한 연구

이병호; 김동건; 정원훈; 김봉환

논문 상세보기

각도 분할 인덱스 척의 구조 안정성에 대한 연구 KCI 등재

A Study on the Structural Stability of the Index Chuck with Angle Division

이병호, 김동건, 정원훈, 김봉환

언어KOR
URLhttps://db.koreascholar.com/Article/Detail/415984

구독 기관 인증 시 무료 이용이 가능합니다. 4,000원

한국기계기술학회지 (Journal of the Korean Society of Mechanical Technology)

제24권 제3호 (2022.06)
pp.385-390

한국기계기술학회 (Korean Society of Mechanical Technology)

초록

This paper is about structural, and vibration analysis for the development of Index chucks Structural and vibration analyses were performed using the ANSYS Mechanical program to evaluate the Index chuck's structural stability and vibration characteristics. As a analysis result, when the maximum load of 500N was applied to the Index chuck, the safety factors were 2.06, 2.09, and 2.60, respectively, when the thickness was 5mm, and the outer diameters were 70mm, 90mm, and 120mm, respectively. Structurally safe results were obtained. In addition, under load conditions of 300 N or less, structural safety was confirmed if the thickness is 3mm or more.

키워드

Angle division(각도 분할)Index chuck(인덱스 척)Drilling automation system(드릴링 자동화 시스템)Structural analysis(구조해석)Modal analysis(모드해석)Harmonic analysis(하모닉 해석)

저자

이병호(㈜엘에스케이) | Byeong-Ho Lee
김동건(경상국립대) | Dong-gun Kim
정원훈(경상국립대) | Won-hoon Jung
김봉환(경상국립대학교) | Bonghwan Kim Corresponding author
