Heavy bitumen scattered in the underground sedimentary layer is a kind of unconventional energy source, and by extracting it, a production well is excavated in the sedimentary layer and high-temperature and high-pressure steam is injected to reduce the viscosity of bitumen and recover it to the ground steam assisted method is applied. As a recovery method that uses the steam effect of the dilution effect of solvent injection, it is a recovery method that can increase thermal efficiency. In this study, the process system of the central processing facility(CPF) of the hybrid steam-solvent recovery method that injects solvent into the existing steam assisted method was analyzed, and the core facilities for each process were identified, and hybrid steam-solvent recovery compared to the existing steam assisted method. In the case of the method, it was evaluated that the amount of steam supply and all utility costs decreased according to the solvent injection.

• 정진홍(가온이엔에스(주)) | Jin-Hong Jung Corresponding author
