The sub-frame is located on the lower body of a monocoque type vehicle and serves as an engine and suspension, and is an important object part that receives a lot of load. The existing press-type sub-frame has a large number of parts for assembling, which causes an increase in cost. Changing the machining form of this part from the existing press-type machining method to the hydro-forming machining method has the advantage of reducing the cost and weight at the same time due to the reduction of the process. Therefore, in this study, the purpose of this study is to change the design so that the sub-frame of the existing press type can be changed to the hydro-forming process method. To this end, we intend to present a design method by analyzing the effect on the rigidity of the sub-frame using the existing machining method through shape optimization analysis.

• 이재웅(중부대학교) | Jae-Woong Lee Corresponding author
• 김기주(동명대학교 메카트로닉스공학과)
