A spiral flow path was applied to solve the problem of the existing straight flow path in the leveling shaft, a key component of the self-levelizer that can maintain the height according to the change in payload in EV, SUV. In this study, flow analysis was performed to check the velocity, pressure drop, and flow direction of oil according to the main operating conditions of the leveling shaft with a spiral flow path. As a result of the study, a leveling shaft with a spiral flow path is likely to improve fluid properties around the orifice and inlet valve under compression conditions, and it is judged to have a development application effect.

• 박경민 (전주비전대학교) | Kyungmin Park
• 백일현(전주비전대학교) | Baek Il Hyun
