In a self-level riser, the piston rod generates hydraulic pressure while reciprocating along the pump rod, so components such as rods and valves require precise processing technology. Among them, the design of the pump rod was changed to a spiral groove method because there was a risk of poor operation during eccentricity. In this paper, the design and 3D modeling of the pump rod were conducted, and the structural stability of the core part according to the load change applied to the pump rod was confirmed.
