pp.21-25
PURPOSES : The objectives of this study are to evaluate the condition of concrete bridge decks using the multi-channel ground penetrating radar (GPR) testing and compare the value of its dielectric constant value with actual concrete condition. METHODS : The reflection coefficient method was used to measure the dielectric properties of concrete bridge decks. Air-coupled step-frequency GPR testing was used to measure the time taken for reflection from the interfaces between the layers. Specimens of the asphalt mixture and concrete bridge-deck were collected by field coring. GPR testing was conducted on two bridges with different concrete bridge deck conditions on national highways. After the GPR tests, the actual conditions of the concrete bridge deck were investigated using specimen coring. RESULTS : GPR testing indicated that the dielectric constants of concrete bridge decks in good condition ranged from 8 to 10, whereas those corresponding to poor condition ranged from 4 to 6. The results of GPR testing can determine the actual condition and degree of distress of concrete bridge decks determined from the specimen coring data. Therefore, GPR testing is appropriate for nondestructively evaluating the condition of a concrete bridge deck. CONCLUSIONS : The analysis results of the dielectric constants of the concrete bridge deck obtained from multichannel GPR testing were consistent with the actual bridge deck conditions. In the near future, an additional verification process for this approach under different bridge conditions will be required to improve its precision and ensure reliability.
2. 조사장비 및 조사방법
3. 분석방법
4. 분석결과
5. GPR 시험 검증
6. 결론
감사의 글
