Scanning probe microscopy (SPM) has become an indispensable tool in efforts to develop the next generation of nanoelectronic devices, given its achievable nanometer spatial resolution and highly versatile ability to measure a variety of properties. Recently a new scanning probe microscope was developed to overcome the tip degradation problem of the classic SPM. The main advantage of this new method, called Reverse tip sample (RTS) SPM, is that a single tip can be replaced by a chip containing hundreds to thousands of tips. Generally for use in RTS SPM, pyramid-shaped diamond tips are made by molding on a silicon substrate. Combining RTS SPM with Scanning spreading resistance microscopy (SSRM) using the diamond tip offers the potential to perform 3D profiling of semiconductor materials. However, damage frequently occurs to the completed tips because of the complex manufacturing process. In this work, we design, fabricate, and evaluate an RTS tip chip prototype to simplify the complex manufacturing process, prevent tip damage, and shorten manufacturing time.

1. 서 론
2. 실험 방법
    2.1. RTS tip-chip 구조 디자인
    2.2. RTS tip-chip 제작
3. 결과 및 고찰
    3.1. 탐침 형상
    3.2. 탐침 평가
4. 결 론
Acknowledgement
References
<저자소개>

• 김수길(전남대학교 신소재공학과) | Sugil Gim (Department of Materials Science and Engineering, Chonnam National University, Gwangju 61186, Republic of Korea)
• Thomas Hantschel(IMEC)
• 김진혁(전남대학교 신소재공학과) | Jin Hyeok Kim (Department of Materials Science and Engineering, Chonnam National University, Gwangju 61186, Republic of Korea) Corresponding author
