In this study, the shape evaluation and design of clamp mount for SUVs (sports utility vehicles) was dealt with through structural analysis. The clamp mount analysis was performed to evaluate stiffness, strength and improvement plans for appropriate shape were found and reflected in the design. In addition, strength analysis and was performed in parallel to solve the problem of rib design around the edge part of the clamp mount and the thickness effect results were reflected in the design. As a result of analysis through various design changes, it was possible to present an appropriate reinforcement design shape. In addition, when the thickness of the fuel tank was changed from 3.2mm to 4.0mm, the stiffness of the fuel tank decreased by approximately 30%, and reinforcement was required.

• 이재웅(중부대학교) | Jae-Woong Lee Corresponding author
