The adhesive design of a fast steering mirror transmitting a high power laser is one of the important design elements that affect optical aberration of the mirror surface. In this paper, we designed the adhesive part to avoid the high power laser beam of the FSM system. Stiffness and wavefront error are trade-off relationships and an optical design was derived to maintain the wavefront error of the mirror surface at high temperatures while satisfying the bandwidth of the FSM system. For the optimal design of the mirror bonding position, structural analysis was conducted using ANSYS and wavefront error analysis was performed using Zernike polynomial code. Through those analysis, FSM most effective at an angle 60 degrees and a distance of 46mm.

• 남성식(Ground Technology Research Institute, Agency for Defense Development) Corresponding author
• 최인준 (Agency for Defense Development)
