On-machine automatic measuring software from 3-D solid modeler is generally applied to assess the functional performance of a final produce for computer numerical control (CNC) machine. Automatic measuring software may also be performed on individual components of CNC machine in which some functional aspect of the component must be examined and cannot be implicity determined by means of a mechanical inspection. The manufacturing specialist, combined with the appropriate software simulation, can not only create the commands to drive the virtual measuring but also can check for mistakes by viewing the computer graphics simulation of the tool cutting sequence.

• 김옥삼 | Kim, Ok-Sam
