The new empirical static model was constructed on the basis of dimension analysis to predict the pressure drop according to the operating conditions. The empirical static model consists of the initial pressure drop term (N dust = ω0υf / P pulse t) and the dust mass number term (Δp initial), and two parameters (dust deposit resistance and exponent of dust mass number) have been estimated from experimental data. The optimum injection distance was identified in the 64 experimental data at the fixed filtration velocity and pulse pressure. The dust deposit resistance (K d), one of the empirical static model parameters got the minimum value at , d=0.11m, at which the total pressure drop was minimized. The exponent of dust mass number was interpreted as the elasticity of pressure drop to the dust mass number. The elasticity of the unimodal behavior had also a maximum value at , d=0.11m, at which the pressure drop increased most rapidly with the dust mass number. Additionally, the correlation coefficient for the new empirical static model was 0.914.

Abstract
 1. 서 론
 2. 재료 및 방법
  2.1. 실험재료
  2.2. 실험장치
  2.3. 실험방법
 3. 모델링
  3.1. 차원분석 경험모델 (Empirical static model bydimension analysis)
 4. 결과 및 고찰
  4.1. 초기 압력손실 (Initial pressure drop)
  4.2. 분진 질량 수 (Dust mass numbers)에 대한 압력손실 영향
  4.3. 모델 검증
 5. 결 론
 참 고 문 헌

• 서정민(부산대학교 지역환경시스템공학과) | Jeong-Min Suh (Department of Regional Environmental System Engineering, Pusan National University)
• 박정호(진주산업대학교 환경공학과) | Jeong-Ho Park (Department of Environmental Engineering, Jinju National University) Corresponding Author
• 임우택(안동대학교 응용화학과) | Woo-Taik Lim (Department of Applied Chemistry, Andong National University)
