SUS 육각봉 인발성형 시스템의 클램프 가이드 바에 관한 구조해석

이영식; 양영준

논문 상세보기

SUS 육각봉 인발성형 시스템의 클램프 가이드 바에 관한 구조해석 KCI 등재

Structural Analysis on Clamp Guide Bar of Drawing Process System for SUS Hexagonal Bar

이영식, 양영준

언어KOR
URLhttps://db.koreascholar.com/Article/Detail/366086

구독 기관 인증 시 무료 이용이 가능합니다. 4,000원

한국기계기술학회지 (Journal of the Korean Society of Mechanical Technology)

제20권 제6호 (2018.12)
pp.796-802

한국기계기술학회 (Korean Society of Mechanical Technology)

초록

In order to remove rust and impurities from surface of raw SUS circular bar, peeling machine is used to make lustrous and clean surface of SUS circular bar. Drawing process system is used to manufacture SUS hexagonal bar. SUS hexagonal bar have been widely used to make hexagonal bolt/nut, adapter and fittings and so on. The purpose of this study is to investigate the stabilities for guide bar of clamp in drawing process system. As the results, the guide bar showed structural stability in cases of below load of 50 Ton and over hook radius of 3.0mm. Further as the thickness of guide bar hooking with jaw was increased, minimum safety factor was decreased.

키워드

Drawing Process System 인발성형 시스템 Clamp 클램프 Guide Bar 가이드 바 SUS Hexagonal Bar SUS 육각봉 Safety Factor 안전율

ABSTRACT
1. 서 론
2. 인발 공정(Drawing process)
3. 모델링 및 수치해석 방법
4. 해석결과 및 고찰
5. 결 론
References

저자

이영식(Han Young Machinery Co., Ltd.) | Young-Sik Lee
양영준(Automotive Eng., Gyeongnam Nat'l Univ. of Sci. & Tech.) | Young-Joon Yang Corresponding Author
