스퍼터링 공정 압력이 InZnO 박막트랜지스터의 광학 및 전기적 특성에 미치는 영향 KCI 등재 SCOPUS

Effect of Sputtering Working Pressure on the Optical and Electrical Properties of InZnO Thin-Film Transistors

  • 언어KOR
  • URLhttps://db.koreascholar.com/Article/Detail/389555
구독 기관 인증 시 무료 이용이 가능합니다. 4,000원
한국재료학회지 (Korean Journal of Materials Research)
한국재료학회 (Materials Research Society Of Korea)
초록

Amorphous In-Ga-Zn-O (a-IGZO) thin film transistors, because of their relatively low mobility, have limits in attempts to fulfill high-end specifications for display backplanes. In-Zn-O (IZO) is a promising semiconductor material for high mobility device applications with excellent transparency to visible light region and low temperature process capability. In this paper, the effects of working pressure on the physical and electrical properties of IZO films and thin film transistors are investigated. The working pressure is modulated from 2 mTorr to 5 mTorr, whereas the other process conditions are fixed. As the working pressure increases, the extracted optical band gap of IZO films gradually decreases. Absorption coefficient spectra indicate that subgap states increase at high working pressure. Furthermore, IZO film fabricated at low working pressure shows smoother surface morphology. As a result, IZO thin film transistors with optimum conditions exhibit excellent switching characteristics with high mobility (≥ 30cm2/Vs) and large on/off ratio.

목차
Abstract
1. 서 론
2. 실험 방법
3. 결과 및 고찰
4. 결 론
References
저자
  • 박지민(충남대학교 신소재공학과) | Ji-Min Park (Department of Materials Science and Engineering, Chungnam National University)
  • 김형도(충남대학교 신소재공학과) | Hyoung-Do Kim (Department of Materials Science and Engineering, Chungnam National University)
  • 장성철(충남대학교 신소재공학과) | Seong Cheol Jang (Department of Materials Science and Engineering, Chungnam National University)
  • 김현석(충남대학교 신소재공학과) | Hyun-Suk Kim (Department of Materials Science and Engineering, Chungnam National University) Corresponding author
