pp.105-112
PURPOSES : High concentrations of particulate matter (PM) are emitted or generated from vehicle emissions in urban roads with dense transient populations. To reduce the effect of PM emission on bus stop users at roadsides, a plan to reduce PM emitted from the roadside must be devised. In this study, an atmospheric environment at a roadside is simulated in a large-scale environment chamber, and a test for reducing PM around the bus stop is conducted by installing a bus stop adapted to a PM reduction system.
METHODS : Exhaust gas is injected into the experimental and reference chambers using diesel and gasoline vehicles for roadside airquality simulations. The two vehicles are operated in an idle state without an acceleration operation to emit exhaust gas uniformly, and the initial conditions are achieved by injecting car emissions for approximately 40 min. The initial condition is set to 1 ppm of NOx concentration in the environment chamber. Between the two environment chambers, a bus stop adapted to the PM reduction system is installed in the experimental chamber to conduct a PM reduction experiment pertaining to the air quality around the roadside. The experimental progress is set as the start time of the experiment based on the time at which the initial conditions are achieved; simultaneously, the PM reduction system in the experimental chamber is operated. After the simulation is commenced, the PM concentration, which changes over time, is measured using a high-resolution time-of-flight aerosol mass spectrometer (HR-ToF-AMS) without additional injection of car emissions or pollutants. The HR-ToF-AMS measures the chemical composition of non-refractory PM1.0 (NR-PM1.0) in real time.
RESULTS : The NR-PM1.0 compound (organic aerosol (OA), NO3 -, SO4 2-) increases by 160% compared with the simulated initial concentration up to T90min in both environmental chambers; this is speculated to be due to secondary formation. The reference chamber indicates a slight decrease or a steady-state after T90min, whereas the experimental chamber indicates a gradually decrease as the experiment progresses. The bus stop adapted to the PM reduction system reduces the amount of black carbon in the experimental chamber by 37% at 200 min. This implies that the PM emitted from the roadside is filtered via the PM reduction system installed at the bus stop, and cleaner air quality can be provided to passengers.
CONCLUSIONS : The PM reduction system evaluated in this study can be detached from and attached to the outdoor billboard of a bus stop. Since it adopts air filtration technology that uses a high-efficiency particulate air filter, it can be maintained and managed easily. In addition, it can provide an atmospheric environment with reduced PM emission to passengers as well as provide a better air-quality condition to passengers waiting for public transportation near roadsides.
1. 서론
2. 연구방법
2.1. 실대형 미세먼지 실증 챔버
2.2. 버스정류장 초미세먼지 저감 수직녹화시스템
2.3. 측정 방법
2.4. 연구 구성
3. 결과 및 고찰
3.1. 실증 챔버 내 초미세먼지의 농도 변화
3.2. 미세먼지 저감 수직녹화시스템 적용 버스정류장의초미세먼지 저감율
4. 결론
REFERENCES
