The Sungnyemun roofing tiles were twice disassembled for maintenance work, in 1963 and 1997, and modern tiles were applied in 1997. However, besides differing in visual appearance, the modern tiles had distinctly different physical properties. A study has been carried out on 22 different tiles, including original Sungnyemun tiles, modern tiles applied during maintenance, traditional tiles made by tile-makers, and others, to examine their physical properties, such as bending strength, frost resistance, absorption, whole-rock magnetic susceptibility, chromaticity, differential thermal analysis, and other characteristics. Since the method of making modern tiles involves compressing clay in a vacuum, modern tiles showed relatively greater bending strength and specific gravity, while Sungnyemun tiles and those made by tile-makers, in comparison, demonstrated less bending strength and specific gravity owing to their production method of 'treading,' in which clay is mixed by having someone tread upon it repeatedly. Over time, the absorption rate of the original tile used for Sungyemun gradually decreased from 21% to 14.7%; traditional tiles from tile-makers showed absorption rates of 17%, while the absorption rate of modern tiles was just 1%, which is significantly low. As for frost resistance, Sungnyemun tiles and traditional tiles from tile-makers showed cracking and exfoliation after being subjected to testing 4 or 5 times, while slight cracking was seen on the surface for modern tiles after 1ngy, or 3 times. In other words, no significant difference from influence by frost was found. According to the results of differential thermal analysis, the plastic temperature was shown to have been no less than 1, on℃ for all types of tile, and cristobalite was measuredthrough XRD analysis from a Sungnyemun female tile applied during maintenance in 1963, which appeared to have been plasticized at between 1,200℃~1,300℃. Based on these research results on the physical properties of tiles from the Sungnyemun roof, a fundamental production method for tiles to be applied in the restoration of Sungnyemun has been identified.

1. 서론
2. 분석기기
    2-1. 색도계
    2-2. 시차열분석(Differential ThermalAnalysis, DTA)
    2-3. 전암대자율
    2-4. 열적외선 조사
    2-5. X선 회절분석
3. 연구방법
    3-1. 대상시료
    3-2. 분석방법
4. 결과 및 고찰
    4-1. 휨강도
    4-2. 내동해성
    4-3. 비중과 흡수율
    4-4. 전암대자율
    4-5. 색도
    4-6. 시차열분석
    4-7. X선 회절분석(XRD)
5. 결론
참고문헌
Abstract

• 정광용(한국전통문화학교 보존과학과 교수) | Chung, Kwang-Yong (Dept. of Conservation Science, The National University of Cultural Heritage) Corresponding author
