본 연구에서는 PVDF 중공사막을 열유도상분리와 연신의 복합공정에 의해 제조하였으며, 연신비에 따른 분리막의 구조 및 물성을 분석하였다. 이 분리막 제조의 메카니즘은 액-액 상분리에 기초하며, 최종 중공사막은 bicontinuous한 구조와 연신에 의해 fibrill 구조를 가지게 되어, 구정(spherulite)구조를 갖는 고-액 상분리막과 bicontinuous한 구조만을 갖는 액-액상분리막과 차별화된다. 우선, TIPS공정을 통해, gamma-butyrolacton, dimethyl phthalate (DMP), diethyl phthalate (DEP), di-butyl phthalate (DBP) 등을 단일 혹은 이들을 조합한 혼합 diluent로 사용하여, 냉각조건, PVDF와 희석제의 함량을 조절하면서 중공사막 전구체를 제조하고, 후속공정인 연신에 의해 최종적으로 중공사막의 외부표면을 porous하게, 혹은 dense하게 만들 수 있었다. 연신된 중공사막을 에탄올에 추출, 건조한 후 SEM을 통하여 pore 구조의 변화를 관찰하였으며, 수투과량, 다공도, 기공 크기, 표면 거칠기, 인장강도 등의 변화를 분석하였다.
In this research, microporous and bicontinuous poly vinylidene fluoride(PVDF) hollow fiber membranes were prepared via hybrid process of the thermally induced phase separation (TIPS) and stretching method. The mechanism of the membrane preparation is based on liquid-liquid phase separation. The final membranes have characteristic structures which have both bicontinuous and fibrillar morphology by applying the stretching method. They showed quite different structure when compared with the spherulitic or nodular structure from S/L TIPS and bicontinuous structure from L/L TIPS. At first, PVDF hollow fiber precursors were prepared via TIPS method using various kind of diluent mixtures. We used gamma-bu-tyrolacton, dimethyl phthalate (DMP), diethyl phthalate (DEP), dibutyl phthalate (DBP) as diluents. We could make hollow fiber membranes which had porous outer surface or dense outer surface by controling the parameters such as cooling con-ditions, PVDF concentration and the ratio of diluent mixtures. Finally, these hollow fiber were stretched at room temperature and diluents were extracted by ethanol. Effects of the stretching ratio on the membrane morphology were investigated using scanning electron microscope (SEM), and its effects on water flux, porosity, pore size, roughness and tensile strength were examined.
