pp.123-130
U-flanged truss beam is composed of u-shaped upper steel flange, lower steel plate of 8mm or more thickness, and connecting lattice bars welded on the upper and lower sides. The hybrid beam with U-flanged steel truss is made in the construction site through pouring the concrete, and designated as U-flanged truss hybrid beam. In this study the structural experiments on the 4 hybrid beams with the proposed basic shapes were performed, and the flexural capacities from the tests were compared with those from the theoretical approach. The failure modes of each specimen were quite similar. The peak load was reached with the ductile behavior after yielding, and the failure occurred through the concrete crushing. The considerable increasement of deformation was observed up to the concrete crushing. The composite action of concrete and steel member was considered to be reliable from the behavior of specimens. The flexural strength of hybrid beam has been evaluated exactly using the calculation method applied in the boubly reinforced concrete beam. The placement of additional rebars in the bottom instead of upper side is proposed for the efficient design of U-flanged truss hybrid beam.
1. 서론
2. 실험 계획
2.1 실험체 계획
2.2 가력 방법 및 측정 방법
3. 실험 결과 및 분석
3.1 금속 재료 인장 강도 시험
3.2 콘크리트 압축 강도 시험
3.3 파괴 양상
3.4 힘-변위 관계
3.5 기존 설계식을 이용한 휨 강도 평가
4. 결론
References
