V-type coupling, which is often applied to wastegate-turbochargers(WGT), is a mechanical fastener. Its radial forces generated from the bolt pretension load colse contact with each other to the axial direction for turbine housing and center housing rotating assembly(CHRA). In addition, the torsional stiffness between two bodies should be sufficiently secured to minimize the linkage angle change from the EWGA to the valve spindle. Therefore, in this study, the torsional stiffnesses according to the effects of positioning pins and friction coefficient, and the bolt pretension loads were calculated for V-coupling turbocharger. As a result, it can be seen that the torsional stiffness of the coupling according to the number of position pins is very small. And, when the friction coefficient and the axial force of the bolt are large, the torsional stiffness is greatly increased, and gradually decreasing when the bolt load of the coupling is about 6,000 N or more.

• 김형준(계양정밀) | Hyung-Jun Kim
• 이영훈(계양정밀) | Young-Hoon Lee
• 최복록(강릉원주대학교) | Choi Boklok Corresponding author
