pp.33-40
We used Cu as a representative of metals to be directly adsorbed on the bare Si surface and studied its removal DHF, DHF-H2O2 and BHF solution. It has been found that Cu ion in DHF adheres on every Si wafer surface that we used in our study (n, p, n+, p+) especially on the n+-Si surface. The DHF-H2O2 solution is found to be effective in removing metals featuring high electronegativity such as Cu from the p-Si and n-Si wafers. Even when the DHF-H2O2 solution has Cu ions at the concentration of 1ppm, the solution is found effective in cleaning the wafer. In the case the n+-Si and p+-Si wafers, however, their surfaces get contaminated with Cu When Cu ion of 10ppb remains in the DHF-H2O2 solution. When BHF is used, Cu in BHF is more likely to contaminate the n+-Si wafer. It is also revealed that the surfactant added to BHF improve wettability onto p-Si, n-Si and p+-Si wafer surface. This effect of the surfactant, however, is not observed on the n+-Si wafer and is increased when it is immersed in the DHF-H2O2 solution for 10min. The rate of the metallic contamination on the n+-Si wafer is found to be much higher than on the other Si wafers. In order to suppress the metallic contamination on every type of Si surface below 1010atoms/cm2, the metallic concentration in ultra pure water and high-purity DHF which is employed at the final stage of the cleaning process must be lowered below the part per trillion level. The DHF-H2O2 solution, however, degrades surface roughness on the substrate with the n+ and p+ surfaces. In order to remove metallic impurities on these surfaces, there is no choice at present but to use the NH4OH-H2O2-H2O and HCl-H2O2-H2O cleaning.
