The HTCC based multilayer structure plasma head unit have some difficulties in fabrication due to complicated post-processes, such as heat treatment at reduced atmosphere, re-bonding of each layer, and silver metallization. On the other hand, LTCC based technology provides relatively simple process for multilayer plasma unit except weak mechanical properties. To overcome this problem a combined scheme using both LTCC and HTCC technology has been developed in our group, recently. In this work, we report the structural design, materials selection, joining of LTCC with HTCC substrate, and co-firing process for the fabrication of multilayered atmospheric plasma head unit.

• Kim
• Hyo-Tae
• Nam
• Myung-Hwa
• Chun
• Byung-Joon
• Kim
• Jong-Hee
